BAJAJ Bronze Valves

Get a Price/Quote

BAJAJ Bronze Valves Specification

Color
Golden

Usage
suitable for both above-ground and underground installation.

Type
Valve

Power
Hydraulic

Pressure
Medium Pressure

Media
Water, Gas

BAJAJ Bronze Valves Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
500 Pieces Per Day

Delivery Time
2 Week

Main Domestic Market
All India

About BAJAJ Bronze Valves

Clients can avail from us an impeccable range of Bronze Valves that we manufacture from quality corrosion resistant bronze obtained from trusted vendors. These valves are commonly used for controlling the pressure and flow of heated water vapor and steam. These Bronze Valves are easy to use and can maintain high volume and flow of temperature.

Features

Unmatched quality
Technically sturdy and strong
Corrosion resistant finish

Bajaj Bronze Fusible Plug IBR Certified

Single Piece / Two Piece Design
Screwed Male BSP Taper End

Max. B.O.P. 100 psig. & 250 psig at 220^oC Temp.
Hyd. Tested 500 psig.
Size 15 mm to 50 mm.

Bajaj Bronze Accessible Feed Check Valve IBR Certified

Straight / Curved Inlet Angle Pattern Bolted Bonned
SS (AISI 410) Trim Parts, Flanged Ends to BS: 10 Table 'H'
Hand Wheel Operated

Max. W.P. 250 psig. at 220^oC Temp.
Hyd. Tested 500 psig.
Size 20 mm to 50 mm.

Bajaj Bronze Spring Loaded Metallic Diaphragm Type Pressure Reducing Valve IBR Certified

Screwed Female Ends spring Available

Range Pr. 5/60, 20/80 and 40/125 on Down Steam
Max. Inlet Pr. 250 psig. at 220^oC Temp.
Hyd. Tested 500 psig.
Size 15 mm to 50 mm.

Bajaj Bronze Parallel Slide Blow Off Valve IBR Certified

With S.S. / Monal Working Parts / Rack & Pinion operated Heav Pattern. BS: 10 Table 'H'

Max. BOP 250 psig. at 220^oC Temp.
Hyd. Tested 500 psig.
Size 25 mm to 50 mm.

Bajaj Bronze Controllable Feed Check Valve IBR Certified

Outsde Screw & Yoke type, with S.S. (AISI-410)
Trim Parts, Bolted Bonnet, S.S. (AISI-410) STem
Screwed / Flanged Ends.

Max. W.P. 250 psig. at 220^oC Temp.
Hyd. Tested 500 psig.
Size 20 mm to 50 mm.

Bajaj Bronze Pressure Gauge Cock IBR Certified

Fitted with Pressure Gauge Coupling Nut and Tail Pipe, Screwed BSP, Female Ends.

Max. W.P. 250 psig. at 220^oC Temp.
Hyd. Tested 500 psig.
Size 100 mm to 15 mm.

Bajaj Bronze Inspectors Test Gauge Cock IBR Certified

With bend 3/4 BSW
Inspector Gauge Connection

Max. W.P. 250 psig. at 220^oC Temp.
Hyd. Tested 500 psig.
Size 10 mm to 15 mm.
